10,000 lbTwo-Post · Floor-Plate · F10
F10
10,000 lb floor-plate two-post.
Frame-engaging rubber-padded truck adapters with multiple adapter extensions to raise most vehicles on the road today. Includes four each of 3.5″ and 5″ extensions. Third-party tested by ETL and approved by ALI.
Capacity
10,000 lb
Lift height
73 in
Full rise
45 sec
From
$5,674
Freight & install quoted separately
ALIETL
Specifications
Full spec sheet.
Tested to fail at 3× rated capacity. Certified, stamped, and shipped with documentation your insurance carrier will accept on the first try.
| Model number | F10 |
| Lift type | Two-Post · Floor-Plate |
| Capacity | 10,000 lb |
| Maximum lift height | 73 in |
| Overall height | 113 in |
| Overall width | 132 in |
| Motor | 2 HP · 220V / 1-ph |
| Full rise time | 45 seconds |
| Shipping weight | 1,685 lb |
| Certifications | ALI, ETL |
| Warranty | 5 years structural, 2 years powertrain |
Features
What you get.
01
10,000 lb capacity for cars, trucks, and vans
02
3-stage front arms, 2-stage rear arms
03
Adapter storage bracket kit included
04
Hydraulic cylinders in each column with Direct-Pull lifting
05
Top-mounted full-stroke cylinders, concealed rods
06
Frame-engaging rubber-padded truck adapters
